End Connection
Type |
Type
Description |
Hose Size
(# of Different Sizes) |
 |
Male Pipe Rigid Straight (NPTF) |
From 1/4 inch
to 1 inch (15) |
 |
Male JIC 37° Flare |
From 1/4 inch
to 1 inch (15) |
 |
Male JIS/BSP Taper Pipe |
From 1/4 inch
to 1 inch (9) |
 |
Female Swivel O-Ring Face Seal |
From 1/4 inch
to 1 inch (15) |
 |
Female Swivel O-Ring Face Seal (45° Bent Tube) |
From 1/4 inch
to 1 inch (13) |
 |
Female Swivel O-Ring Face Seal (90° Bent Tube) |
From 1/4 inch
to 1 inch (15) |
 |
Female Swivel JIC 37° Flare |
From 1/4 inch
to 1 inch (21) |
 |
Female Swivel 37° Flare (45° Bent Tube) |
From 1/4 inch
to 1 inch (12) |
 |
Female Swivel 37° Flare (90° Bent Tube) |
From 1/4 inch
to 1 inch (14) |
 |
Female Swivel 60° Cone (BSPP) |
From 1/4 inch
to 1 inch (14) |
 |
Female Swivel 60° Cone (45° Bent Tube BSPP) |
From 1/4 inch
to 1 inch (8) |
 |
Female Swivel 60° Cone (90° Bent Tube BSPP) |
From 1/4 inch
to 1 inch (9) |
 |
Code 61 Flange Straight (SAE) |
From 1/2 inch
to 1 inch (6) |
 |
Code 61 Flange (45° Bent Tube SAE) |
From 1/2 inch
to 1 inch (7) |
 |
Code 61 Flange (90° Bent Tube SAE) |
From 1/2 inch
to 1 inch (6) |
Recommended Hose Types
