| “JWE will lead as a stainless steel fittings and adapters manufacturer that creates, develops, and maintains customer values through quality products, low prices, customer-centric services, advanced delivery system, and work-ethic.”
|
| |
 Recommended Hose Types |
| 100R1AT, 100R2AT, 100R3, 100R4, 100R5, 100R6, 100R7, 100R8, 100R16, 100R17 |
| Materials |
| Available for both steel and stainless steel |
| End Connection Types and Hose Sizes |
|
End Connection
Type |
Type
Description |
Hose Size |
 |
Male Pipe Rigid Straight (NPTF) |
From 1/4 inch
to 1 inch |
 |
Male JIC 37° Flare |
From 1/4 inch
to 1 inch |
 |
Male JIS/BSP Taper Pipe |
From 1/4 inch
to 1 inch |
 |
Female Swivel O-Ring Face Seal |
From 1/4 inch
to 1 inch |
 |
Female Swivel O-Ring Face Seal (45° Bent Tube) |
From 1/4 inch
to 1 inch |
 |
Female Swivel O-Ring Face Seal (90° Bent Tube) |
From 1/4 inch
to 1 inch |
 |
Female Swivel JIC 37° Flare |
From 1/4 inch
to 1 inch |
 |
Female Swivel 37° Flare (45° Bent Tube) |
From 1/4 inch
to 1 inch |
 |
Female Swivel 37° Flare (90° Bent Tube) |
From 1/4 inch
to 1 inch |
 |
Female Swivel 60° Cone (BSPP) |
From 1/4 inch
to 1 inch |
 |
Female Swivel 60° Cone (45° Bent Tube BSPP) |
From 1/4 inch
to 1 inch |
 |
Female Swivel 60° Cone (90° Bent Tube BSPP) |
From 1/4 inch
to 1 inch |
 |
Code 61 Flange Straight (SAE) |
From 1/4 inch
to 1 inch |
 |
Code 61 Flange (45° Bent Tube SAE) |
From 1/4 inch
to 1 inch |
 |
Code 61 Flange (90° Bent Tube SAE) |
From 1/4 inch
to 1 inch |
|
| Note : Product specification should be discussed before sales. The E-Catalog is ready for your review. For the addtional support, please email me.
(US : jmin@joongwoo.co.kr / Korea : thmin@joongwoo.co.kr) |
|
|
